ORTOFON DJ Stylus DJ E

Name: Stylus DJ E
Brand: ORTOFON DJ
SKU: 341434
Price: 59.00 EUR
Availability: InStock

59,00 €VAT incl.

0,00 € Ecotax included

Reference price

In stock online

Store: on order

Estimated Shipping Widget will be displayed here!

ID : 341434

EAN : 5705796140040

ORTOFON DJ

What you need to know

Replacement stylus specifically designed for the Ortofon Pro S series, ideal for extending the life of your cartridge.
Spherical tip designed for stable playback in DJing (mixing, back-cueing), offering a good balance between groove tracking and durability.
Easy installation: quick stylus replacement with no complex adjustments, perfect for club or mobile setups.
Balanced performance: 5 mV output voltage and a frequency response of 20 to 18,000 Hz for clean reproduction.

Stylus DJ E

59,00 €VAT incl.

0,00 € Ecotax included

Reference price

A stylus designed to stay true to the spirit of the Pro S series

The Stylus DJ E is a replacement stylus developed to preserve the signature sound and tracking performance of Ortofon Pro S cartridges. It is aimed at DJs who want to regain the same feel after wear, while ensuring reliable tracking during handling.

Which DJs and applications is it designed for?

This Ortofon stylus is suitable for beginner to experienced DJs playing on turntables, in home studios, bars/clubs or live performances. Its tracking force range and spherical stylus tip promote stability for mixing and intensive use (beatmatching, back-cueing), while remaining easy to use.

Technical specifications

Frequency response - start	20 Hz	Destination	DJ
Frequency response - end	18 kHz	Diamond tip	spherical
DJing type	Mix	Color	Grey
Category	diamond	Quantity	1
Type	diamond

Internal impedance, DC resistance	750 Ohms	Recommended load resistance	47 kOhms
Internal inductance	450 mH	Recommended load capacitance	200 to 600 pF

Questions frequently asked

Is the Stylus DJ E compatible with an Ortofon Pro S cartridge?

This replacement diamond is dedicated to the Ortofon Pro S series. It allows preserving the signature and tracking behavior associated with this series.

What tracking force should be set with this DJ stylus?

The recommended tracking force is 4.0 g (40 mN). The adjustment range extends from 3.0 to 5.0 g, i.e., 30 to 50 mN.

Spherical or elliptical tip for mixing: what profile does this stylus have?

The spherical tip has a radius of R 26 µm. This profile favors stable playback during mixing and back-cueing.

Is this stylus suitable for scratching and cueing?

Its tracking ability is rated at 70 µm at 315 Hz with the recommended tracking force. The lateral dynamic compliance is 7 µm/mN. These values support intensive manipulations on vinyl turntables.
